SILISIL RTV MD-Soft 10

SILISIL RTV MD-Soft 10

https://www.silitech.ch/web/image/product.template/3541/image_1920?unique=aa4ff16

SILISIL RTV MD-Soft 10 — Soft silicone Shore A 10 for medical soft-touch applications without direct skin contact, available from Swiss stock.

2K silicone Shore A 10 (translucent, mixing ratio 1:1) — Soft silicone Shore A 10 for medical soft-touch applications without direct contact.

CHF 0.00 CHF 0.00 CHF 0.00 Excluding taxes

CHF 0.00 excluding taxes

Price on request

  • brand
  • Mixing ratio
  • Networking type
  • Paint has hardened
  • Self-leveling
  • Density (g/cm³)
  • Viscosity uncrosslinked (mPa·s)
  • Electrical insulation
  • Potting time (min)
  • Demolding time (min)
  • Full networking (h)
  • Food contact
  • Suitable for medical use
  • Certificates
  • Shore hardness A (cured)
  • Elongation at break (%)
  • Container

This combination does not exist.

Add to cart Request sample
Contact us
SILISIL Silicone RTV-2 Swiss Bearing Addition Platinum Swiss Brand 2K Medical Dental Medical Grade Dental Skin-compatible Shore A 10


General Terms and Conditions.

Shipping usually within 1 to 3 business days
(availability will be confirmed after ordering)

. Express logistics. Fast and reliable within Switzerland & Europe.

Shipping from Swiss warehouse within 24 hours. Batch certificate. Invoice within 30 days (B2B). Technical support.
Shipping & Delivery

Usually 1 to 3 working days

Availability will be confirmed after order receipt.

Express logistics within Switzerland & Europe.

General Terms and Conditions →

Product data

HS code: 3910.0000

HS code: 3910.0000

SILISIL RTV MD-Soft 10
SILISIL RTV MD-Soft 10
SILISIL ·

SILISIL RTV MD-Soft 10 is a room temperature vulcanizing 2-component silicone of the MD — Medical (Dental, Podiatry, Skin Contact)series (Addition (Platinum), Soft variant, RTV-2) — Soft silicone Shore A 10 for medical soft-touch applications without direct skin contact.

The mixture is prepared in a 1:1 ratio by weight . Pot life at 23 °C is approximately 7 minutes, demolding is possible after approximately 30 minutes, and complete curing takes 24 hours. Temperature resistant from -40 °C to +200 °C.

Key feature

Soft variant Shore A 10 for medical and industrial soft-touch applications without direct skin contact — same mechanics as MD-Skin 10, without skin contact certificate.

SILISIL RTV MD-Soft 10 in figures
A 10
Shore hardness
4'500
mPa·s viscosity
7 min
Pot life @23 °C
600 %
Elongation at break

What distinguishes SILISIL RTV MD-Soft 10

Final hardness Shore A 10 — very soft
High elongation at break 600%
High elasticity — safe demolding of complex geometries without damage to the mold or the original.
Tear resistance 11 N/mm
Solid tear resistance — sufficient for medium production runs with standard materials.
Low viscosity 4,500 mPa·s
Low mixing viscosity — flows into the finest structures without air inclusions, vacuum venting optional.
Potting time 7 minutes
Very short processing time — suitable for high-throughput production with short mold cycles.
Mixing ratio 1:1 by weight
Simple 1:1 ratio — mixable by hand without precision scales, ideal for workshops and hobbyists.

What is SILISIL RTV MD-Soft 10 used for?

Industrial soft-touch components
Keyboard membranes, sensor pads, housing padding and soft controls in the medical device industry.
Medical device components
Soft components without direct skin contact — inner padding, cushions, vibration damping in medical devices.
Training and teaching models
Anatomical models for nursing and medical training with soft tactile sensation — without requirements for skin contact certificates.
Industrial acoustic damping
Vibration and sound damping in precision instruments and measuring equipment — elongation at break 600% absorbs mechanical shocks.
Soft bindings in robotics
Gripper and support components for robots that handle sensitive workpieces.
Mock-up and design models
Soft-touch prototypes for medical device development and industrial design — lifelike feel without medical certification.

processing

1
Prepare the original
Clean, dry and dust-free surface at 23 °C — cooler environments significantly extend pot life and curing time.
2
Mixing components
Stir the base and catalyst thoroughly before use. Weigh out 1:1 by weight. Mix thoroughly, including the sides and bottom of the container.
3
Vacuum venting
For a pore-free mold, briefly vent under vacuum — trapped air is removed and a smooth mold surface is guaranteed.
4
Process
Pour from a height of approximately 30 cm in a thin stream — minimal air inclusions.
5
Vulcanizing and demolding
At 23 °C, demolding is possible after approximately 30 minutes, with complete hardening after 24 hours.
Data sheets & safety data sheet
Full TDS and SDS in DE, EN, FR — view or download directly.
To the documents →

Important instructions

Avoid crosslinking inhibitors
Addition system (platinum) — sensitive to sulfur, amine, tin, and phosphorus compounds. Avoid contact with latex gloves and PVC plasticizers.
Storage and shelf life
In its unopened original container, the product has a shelf life of at least 12 months when stored in a dry, cool place (10–25 °C). Consult the SDS before opening.
Available packaging
1 kg + 1 kg, 5 kg + 5 kg. Other container sizes available on request.
compatibility
Compatible with polyurethane, epoxy, and polyester casting resins. Apply a release agent to aggressive resins.

Recommended accessories

SILISIL Silicone Remover
Cleaning agent for silicone residues on tools, models and work surfaces — gentle and effective.
View product →
SILISIL Vaseline release paste white
Universal release agent for polyester, epoxy and polyurethane casts — protects the silicone mold from aggressive resins and extends the mold's lifespan.
View product →

Which silicone for which application?

SILISIL RTV MD-Soft 10 in direct comparison with related products in our range (MD — Medical (Dental, Podiatry, Skin Contact)).

MD-Soft 10
Current product		 MD-Skin 10 →MD-Soft 0020 →MD-Gel →
Shore hardness A101000 23gel
Mixed viscosity4'5004'5005'2001'000
ColorTranslucentTranslucentTranslucentTranslucent
Pot life @23 °C772510
Mixing ratio1:11:11:11:1
Topics & Application Areas
Key terms related to this product. Also useful for our search and filters.
SILISIL Silicone RTV-2 Swiss Bearing Addition Platinum Swiss Brand 2K Medical Dental Medical Grade Dental Skin-compatible Shore A 10

Technical data for SILISIL RTV MD-Soft 10

All 17 product information 4 Physical properties 4 Electrical properties 1 Curing values ​​3 Product approvals 3 Mechanical properties 2
Product information
brand SILISIL
Mixing ratio 1:1
Networking type Addition (Platinum)
Container 1kg + 1kg, 5kg + 5kg, 10kg + 10kg, 25kg + 25kg
Physical properties
Paint has hardened Translucent
Self-leveling Yes
Density (g/cm³) 1.08
Viscosity uncrosslinked (mPa·s) 4500
Electrical properties
Electrical insulation Yes
Curing values
Potting time (min) 7
Demolding time (min) 30
Full networking (h) 24
Product approvals
Food contact No
Suitable for medical use Yes
Certificates RoHS, REACH
Mechanical properties
Shore hardness A (cured) A 10
Elongation at break (%) 600

For binding values, please refer to the technical data sheet (TDS) in the "Documents" tab.

Documents and datasheets

Click on a document for a preview or the download icon for a direct download.

Technical Data Sheets (TDS) 3
SILISIL RTV MD-Soft 10 - Technical Data Sheet DE.pdf
126 KB
SILISIL RTV MD-Soft 10 - Technical Data Sheet EN.pdf
127 KB
SILISIL RTV MD-Soft 10 - Fiche Technique FR.pdf
127 KB

Frequently asked questions about SILISIL RTV MD-Soft 10

Practical application and design questions — answered by SILITECH.

SILISIL RTV MD-Soft 10 is a 2K silicone from the MD — Medical (dental, podiatry, skin contact) series (Shore A 10, translucent). This Shore A 10 soft silicone is designed for medical soft-touch applications without direct skin contact and is suitable for industrial soft-touch components and related applications.

At 23 °C, the pot life is approximately 7 minutes and the demolding time approximately 30 minutes. Complete curing takes 24 hours.

SILISIL RTV MD-Soft 10 is an addition (platinum), soft variant system. This addition system (platinum) is sensitive to sulfur, amine, tin, and phosphorus compounds. Avoid contact with latex gloves and PVC plasticizers.

SILISIL RTV MD-Soft 10 is mixed in a 1:1 ratio by weight (base to catalyst). Homogenize both components separately before mixing, then thoroughly incorporate them – including the container walls and bottom.

SILISIL RTV MD-Soft 10 achieves a Shore A hardness of 10 (ASTM D 2240), a tensile strength of 3.5 N/mm² (ASTM D 412), an elongation at break of approximately 600% and a tensile strength of 11 N/mm (ASTM D 624).

Your question isn't listed here

Our technical team will advise you personally on material selection, processing questions, and individual requirements. Quickly and competently.

Submit a request Request a sample

Product specifications

Product information
Container 1kg + 1kg or 5kg + 5kg or 10kg + 10kg or 25kg + 25kg
brand SILISIL
Mixing ratio 1:1
Networking type Addition (Platinum)
Physical properties
Paint has hardened Translucent
Self-leveling Yes
Density (g/cm³) 1.08
Viscosity uncrosslinked (mPa·s) 4500
Electrical properties
Electrical insulation Yes
Curing values
Potting time (min) 7
Demolding time (min) 30
Full networking (h) 24
Product approvals
Certificates RoHS or REACH
Food contact No
Suitable for medical use Yes
Mechanical properties
Shore hardness A (cured) A 10
Elongation at break (%) 600
