HS Code:
3910.0000
Technical Data
Typical values, not a specification. The technical data sheet (TDS) is binding.
Product Information
- Brand
- SILISIL
- Mixing Ratio
- 1:1
- Curing type
- Addition (Platinum)
- Container
- 1kg+1kg, 5kg+5kg, 10kg+10kg, 25kg+25kg
Physical Properties
- Cured Color
- Translucent
- Self-leveling
- Yes
- Uncrosslinked viscosity (mPa·s)
- 10'000
Curing values
- Pot life (min)
- 12
- Demolding time (min)
- 40
Product Approvals
- Food contact
- No
Mechanical properties
- Shore hardness A (cured)
- A 10
- Elongation at break (%)
- 650
Product Description
SILISIL RTV MD-Soft 10 is an addition-curing, two-component silicone for soft, elastic parts and special effects. It vulcanizes at room temperature and achieves a Shore A hardness of 10.
Technical guidelines
| Mixing Ratio | 1:1 by weight |
|---|---|
| viscosity of the mixture | 10,000 mPa·s, Brookfield |
| Processing time at 23 °C | 12 min |
| Setting time at 23 °C | 40 min |
| Hardness after 24 hours at 23 °C | Shore A 10 |
| Tensile Strength | 3.3 N/mm² |
| Elongation at break | 650 % |
| Tear resistance | 14 N/mm |
Processing
Homogenize both components before use, weigh them precisely, and mix thoroughly, including the edges and bottom. Use matching base and catalyst from the same batch. Processing and setting times are based on 23°C; higher temperatures will shorten them.
Applications involving body contact
Biological tests for defined contact conditions are available for the underlying manufacturer's quality, ZA SFX 10 WT 10. For a medical device, the complete test reports, processing, and intended use of the finished product must be evaluated together. Pigmentation, additives, and sterilization can influence this evaluation.
