PERMABOND 801

PERMABOND 801

https://www.silitech.ch/web/image/product.template/537/image_1920?unique=d900b8c

Permabond 801 — Cyanoacrylate instant adhesive, viscosity 10-15 mPa·s, Shore D 85.

High-temperature resistant wicking adhesive — flows into prefabricated components through capillary action.

CHF 0.00 CHF 0.00 CHF 0.00 Excluding taxes

CHF 0.00 excluding taxes

Price on request

  • Manufacturer
  • brand
  • Container
  • Color
  • Country of origin
  • Chemical group
  • Viscosity (adhesives)
  • Viscosity mPa·s
  • Maximum gap width (mm)
  • Steel hand strength (sec.)
  • Rubber's hand strength (sec.)
  • Hand strength of phenol (seconds)
  • Steel
  • PVC
  • ABS
  • Shear strength polycarbonate
  • Operating temperature (°C)
  • Hardness (Shore D)
  • Storage temperature (°C)
  • Final strength
  • Dielectric strength

This combination does not exist.

Add to cart Request sample
Contact us
Ethyl cyanoacrylate low viscosity cyanoacrylate adhesive plastic adhesive metal adhesive rubber adhesive industrial superglue PERMABOND 801 high temperature resistant superglue high strength adhesive low viscosity superglue


General Terms and Conditions.

Shipping usually within 1 to 3 business days
(availability will be confirmed after ordering)

. Express logistics. Fast and reliable within Switzerland & Europe.

Shipping from Swiss warehouse within 24 hours. Batch certificate. Invoice within 30 days (B2B). Technical support.
Shipping & Delivery

Usually 1 to 3 working days

Availability will be confirmed after order receipt.

Express logistics within Switzerland & Europe.

General Terms and Conditions →

Product data

Internal reference: 49-801.FLG020

HS code: 3506.9190000

Internal reference: 49-801.FLG020
HS code: 3506.9190000

PERMABOND 801
PERMABOND 801
Permabond · Permabond Engineering Adhesives Ltd · SKU 49-801.FLG020

Permabond 801 is an ultra-low viscosity ethyl cyanoacrylate adhesive with targeted enhanced high-temperature resistance — the Wicking class for applications where conventional superglues fail under heat.

With a viscosity of 10–15 mPa·s, 801 is highly flexible and fills micro-gaps down to 0.05 mm. The liquid migrates into already assembled components via capillary action (wicking) — a property that, combined with the product's heat resistance, is a special feature of the Permabond series.

On steel, 801 delivers a shear strength of 19–23 N/mm²; on ABS and PVC, the fracture test leads to substrate failure. Handling strength on all common substrates is 10 to 15 seconds. Permabond 801 is the wicking variant of the high-temperature series 801 / 802 / 820 / 825.

SPECIAL FEATURE

High-temperature resistant ethyl cyanoacrylate variant in an ultra-low viscosity wicking consistency. Retains significantly more strength at higher temperatures than standard cyanoacrylates — the combination of 10–15 mPa·s and heat resistance is unusual for CA adhesives.

Permabond 801 in numbers
10–15
mPa·s viscosity
0,05
mm gap filling
19–23
N/mm² steel
Hot
High-temperature variant

What distinguishes Permabond 801

Ultra-low viscosity
10–15 mPa·s — Wicking-capable, flows into micro-gaps and into joined components via capillary action.
High temperature resistant
Retains more strength at elevated temperatures than standard cyanoacrylates.
Substrate failure in ABS and PVC
For PVC, the bond is stronger than the plastic substrate even at 10 N/mm².
Steel strength at the highest level
19–23 N/mm² shear strength on blasted steel.
Solvent-free
100% reactive — no mixing, no heat curing.
Tight tolerances
0.05 mm gap filling — microsystem technology and precision bonding.

What is Permabond 801 used for?

High-temperature wicking adhesives
Penetration through capillary action into components that are later exposed to elevated temperatures.
Micromechanics and precision instrument manufacturing
Tight tolerance fits with gap widths down to 0.05 mm.
Electronics manufacturing
Component fixation with simultaneous heat tolerance — for example, for areas near hot components.
Repair and maintenance operations
Subsequent fixing of joined components in temperature-stressed environments.
General industrial assembly
Standard adhesive bonds with increased temperature requirements.

processing

1
Clean surfaces
Bonding surfaces must be clean, dry, and free of grease. Degrease with acetone or isopropanol. Lightly sand aluminum, copper, and their alloys to remove the oxide layer.
2
Use adhesive sparingly
Apply Permabond 801 only drop by drop to a bonding surface — the thin layer is crucial for rapid curing.
3
assembling components
Quickly and correctly align the parts. Apply enough pressure so that the adhesive spreads into a thin film.
4
Secure until firmly in place
Do not disturb or realign until handling strength is reached (typically a few seconds to one minute, depending on the substrate). Final strength is reached after 24 hours.
5
Remove adhesive residue
Excess adhesive can be removed with Permabond CA Solvent 2, nitromethane or acetone.
Data sheets & safety data sheet
Full TDS and SDS in DE, EN, FR — view or download directly.
To the documents →

Recommended accessories

Permabond Activator CSA
Accelerates curing and enables bonding on porous or acidic surfaces.
View product →
Permabond POP Primer
Polyolefin primer for the pretreatment of PP, PE, PTFE and silicone — without a primer, reliable cyanoacrylate bonding is not possible on these materials.
View product →
Permabond Cleaner A Aerosol
Spray cleaner for quick degreasing and preparation of the bonding surfaces before applying cyanoacrylate.
View product →
Permabond CA Solvent 2
Special solvent for removing hardened cyanoacrylate adhesive residue — gentler than acetone or nitromethane.
View product →

Important instructions

Not suitable for / Important notes
For porous or difficult surfaces, Permabond CSA activator is recommended. Permabond POP primer is mandatory before bonding PP, PE, PTFE, or silicone.
storage
Store refrigerated at 2 to 7 °C. Allow the bottle to warm to room temperature before opening – this prevents condensation and protects the shelf life.

Which Permabond is suitable for which application?

Permabond 801 in direct comparison with related cyanoacrylate products.

Permabond 801
Current product		Permabond 802 →Permabond 820 →Permabond 825 →
ChemistryEthyl cyanoacrylateEthyl-CAEthyl-CAEthyl-CA
viscosity10-15 mPa·s90–110 mPa·s100 mPa·s100–150 mPa·s
Maximum gap filling.0.05 mm0.15 mm0.15 mm0.15 mm
Firmly on steel10–15 s10–15 s10–15 s10–20 s
Shear strength steel19-23 N/mm²19-23 N/mm²19-23 N/mm²15–20 N/mm²
Strength / Recommended forTemperature resistant Hot
Hot		Medium viscosity, high temperatureHigh temperature + biocompatiblePremium 180 °C / 1,000 h
Topics & Application Areas
Key terms related to this product. Also useful for our search and filters.
Ethyl cyanoacrylate low viscosity cyanoacrylate adhesive plastic adhesive metal adhesive rubber adhesive industrial superglue PERMABOND 801 high temperature resistant superglue high strength adhesive low viscosity superglue

Technical data for PERMABOND 801

All 21 product information 4 Performance at final strength 2 Physical properties 4 Curing values ​​5 Mechanical properties 1 Shear strength ISO 4587 in N/mm² 3 Thermal properties 2
Product information
Manufacturer Permabond Engineering Adhesives Ltd
brand Permabond
Container 20 g
Country of origin Italy
Performance at final strength
Shear strength polycarbonate >6
Dielectric strength 25 kV/mm
Physical properties
Color colorless
Chemical group Ethyl cyanoacrylate
Viscosity (adhesives) Low viscosity <500 MPas
Viscosity mPa·s 10-15
Curing values
Maximum gap width (mm) 0.05
Steel hand strength (sec.) 10-15
Rubber's hand strength (sec.) 10-15
Hand strength of phenol (seconds) 10-15
Final strength 24 hours
Mechanical properties
Hardness (Shore D) 85
Shear strength ISO 4587 in N/mm²
Steel 19-23
PVC >10
ABS >6
Thermal properties
Operating temperature (°C) -55 to +80
Storage temperature (°C) 2-7

For binding values, please refer to the technical data sheet (TDS) in the "Documents" tab.

Documents and datasheets

Click on a document for a preview or the download icon for a direct download.

Technical Data Sheets (TDS) 6
Permabond 801 - Technical Data Sheet DE.pdf
332 KB
Permabond 801 - Technical Data Sheet DE.pdf
331 KB
Permabond 801 - Technical Data Sheet EN.pdf
523 KB
Permabond 801 - Technical Data Sheet EN.pdf
371 KB
Permabond 801 - Fiche Technique FR.pdf
335 KB
Permabond 801 - Fiche Technique FR.pdf
470 KB
Safety Data Sheets (SDS) 3
Permabond 801 - Safety Data Sheet DE.pdf
335 KB
Permabond 801 - Safety Data Sheet EN.pdf
312 KB
Permabond 801 - Fiche de Sécurité FR.pdf
334 KB

Frequently asked questions about Permabond 801

Practical application and design questions — answered by SILITECH.

Permabond 801 is an ethyl cyanoacrylate instant adhesive with a viscosity of 10–15 mPa·s and a maximum gap filling capacity of 0.05 mm. It is an ultra-low viscosity, high-temperature cyanoacrylate adhesive—wicking-capable and highly heat-resistant.

Permabond 801 reliably bonds steel (19–23 N/mm²), ABS (>6 N/mm² (substrate failure)), PVC (>10 N/mm² (substrate failure)), polycarbonate (6 N/mm²), as well as Buna-N rubber and similar elastomers. For polypropylene (PP), polyethylene (PE), PTFE, and silicone, pretreatment with Permabond Polyolefin Primer (POP) is required.

High-temperature resistant ethyl cyanoacrylate variant in an ultra-low viscosity wicking consistency. Retains significantly more strength at higher temperatures than standard cyanoacrylates — the combination of 10–15 mPa·s and heat resistance is unusual for CA adhesives.

Permabond 801 reaches handling strength on steel in 10–15 s. Other typical curing times: 10–15 s (Buna N), 10–15 s (Phenol). The final strength of 19–23 N/mm² (steel) is reached after 24 hours. Temperature, humidity, and substrate affect the curing rate.

Permabond 801 offers a viscosity of 10–15 mPa·s, a gap filling capacity of 0.05 mm, and a shear strength of 19–23 N/mm² on steel. Permabond 802 has a viscosity of 90–110 mPa·s, a gap filling capacity of 0.15 mm, and a shear strength of 19–23 N/mm² on steel (medium viscosity, high temperature). Both utilize an ethyl cyanoacrylate base (or a related cyanoacrylate variant).

Permabond 801 should be stored unopened at 2 to 7 °C and is stable until the printed expiration date. Allow the bottle to warm to room temperature before opening—this prevents condensation inside, which would reduce its shelf life. Opened bottles remain functional for several months if stored correctly, although the curing rate may decrease over time. We recommend a test bond to check reactivity before critical production applications.

From the Permabond cyanoacrylate range, select according to viscosity and special properties: Permabond 801 (10–15 mPa·s, 0.05 mm gap width, temperature resistant); Permabond 802 (90–110 mPa·s, 0.15 mm, medium viscosity, high temperature); Permabond 820 (100 mPa·s, 0.15 mm, high temperature + biocompatible); Permabond 825 (100–150 mPa·s, 0.15 mm, premium 180 °C / 1,000 h). For polypropylene, polyethylene, PTFE, and silicone, pretreatment with Permabond Polyolefin Primer (POP) is always required.

Your question isn't listed here

Our technical team will advise you personally on material selection, processing questions, and individual requirements. Quickly and competently.

Submit a request Request a sample

Product specifications

Product information
Manufacturer Permabond Engineering Adhesives Ltd
brand Permabond
Container 20 g
Country of origin Italy
Performance at final strength
Shear strength polycarbonate >6
Dielectric strength 25 kV/mm
Physical properties
Color colorless
Chemical group Ethyl cyanoacrylate
Viscosity (adhesives) Low viscosity <500 MPas
Viscosity mPa·s 10-15
Curing values
Maximum gap width (mm) 0.05
Steel hand strength (sec.) 10-15
Rubber's hand strength (sec.) 10-15
Hand strength of phenol (seconds) 10-15
Final strength 24 hours
Mechanical properties
Hardness (Shore D) 85
Shear strength ISO 4587 in N/mm²
Steel 19-23
PVC >10
ABS >6
Thermal properties
Operating temperature (°C) -55 to +80
Storage temperature (°C) 2-7
Keywords
Keywords
Ethyl cyanoacrylate low viscosity cyanoacrylate adhesive plastic adhesive metal adhesive rubber adhesive industrial superglue PERMABOND 801 high temperature resistant superglue high strength adhesive low viscosity superglue

Documents and datasheets

Safety Data Sheets (SDS) and Technical Data Sheets (TDS) are available for download:
