BLUESIL ESA 6110 B
Optically clear 2K-Pt silicone gel for the protective encapsulation of highly sensitive electronics — mixing ratio 1:1.
Optically clear 2K-Pt silicone gel for the protective encapsulation of highly sensitive electronics — sensors, solar cells, vibration damping — with QC variant (5 min pot life)
Documents
Internal reference:
40-6110B
HS code:
39100000
Bluesil ESA 6110 A & B is an optically clear 2K-Pt silicone gel for the protective encapsulation of highly sensitive electronics — sensors, solar cells, vibration damping — with QC variant (5 min pot life).
This product line comprises 2K polyaddition silicone gels for the protective encapsulation of highly sensitive electronics — very soft, optically clear, with excellent dielectric properties. ESA 6110 is tailored to specific industrial applications — the most important properties and areas of application are listed below.
Bluesil ESA 6110 is a very soft, optically clear 2-component silicone gel — protecting sensitive electronics from mechanical stress and temperature fluctuations. It is a 1:1 mix with excellent dielectric properties and includes a QC variant (5-minute pot life) for machine application.
What distinguishes ESA 6110
What is ESA 6110 used for?
processing
Recommended accessories
Important instructions
ESA 6110 compared to related RTV products
Networking system, mechanics, and processing times side by side — all values from the official Elkem TDS. “— " = not specified in the datasheet.
ESA 6110 Current product |
ESA 7250 → | RTV 141 → | RTV 147 → | |
|---|---|---|---|---|
| Networking system | 2K Polyaddition (Pt) Gel | 2K Polyaddition (Pt) | 2K Polyaddition (Pt) | 2K Polyaddition (Pt) |
| Mixing ratio | 1 : 1 | 10 : 1 | 10 : 1 | 10 : 1 |
| Color | Visually clear | Optically clear, colorless | Transparent, colorless | Beige / light blue (B) |
| Shore A hardness | Gel (Penetration 250) | A 52 | A 50 | A 60 |
| Elongation at break | — | 115 % | 120 % | 180 % |
| Tensile strength | — | 6.2 MPa | 6 MPa | 6 MPa |
| Tear resistance | — | 4 kN/m | — | >15 kN/m |
| Potting time | 50 min (Std) / 5 min (QC) | 4 h | 4 h | 2 h |
| demolding time | 120–180 min | 24–48 h | 24–48 h | 24–48 h |
| Mixed viscosity | 1,200 mPa·s | 4,000 mPa·s | 4,000 mPa·s | 150,000 mPa·s |
| Main application | Electronic encapsulation (potting) | Electronic potting | Optoelectronic connections | Thermal insulation devices |
Technical data for BLUESIL ESA 6110 B
| Product information | |
|---|---|
| brand | Bluesil |
| Manufacturer | Elkem Silicones |
| Mixing ratio | 1 : 1 |
| Networking type | Addition (Platinum) |
| Number of components | 2K (two-component) |
| consistency | Flowable |
| Mixing ratio | 1:1 |
| Container | 500 g, 1 kg, 5 kg |
| Other features | |
|---|---|
| UV resistance | Yes |
| Physical properties | |
|---|---|
| Paint has hardened | Transparent |
| Self-leveling | Yes |
| Viscosity uncrosslinked (mPa·s) | 1 |
| Electrical properties | |
|---|---|
| Electrical insulation | Yes |
| Curing values | |
|---|---|
| Potting time (min) | 50 |
| Product approvals | |
|---|---|
| Food contact | No |
| Suitable for medical use | No |
For binding values, please refer to the technical data sheet (TDS) in the "Documents" tab.
Documents and datasheets
Click on a document for a preview or the download icon for a direct download.
Frequently asked questions about ESA 6110
Practical questions regarding processing and design — answered by SILITECH.
Bluesil ESA 6110 A & B: Optically clear 2K platinum silicone gel for the protective encapsulation of highly sensitive electronics — sensors, solar cells, vibration damping — with a QC variant (5 min pot life). Main applications are electronics encapsulation (potting), automotive sensors, and solar cell encapsulation.
Polyaddition crosslinking is a two-component silicone chemistry using a platinum catalyst. Component A contains the platinum complex, and component B contains the SiH crosslinker. When mixed, the components crosslink without releasing reaction byproducts—no shrinkage due to outgassing, excellent dimensional accuracy, and low linear shrinkage. Important: Polyaddition silicones are inhibited by various substances—sulfur-vulcanized natural rubbers, tin-catalyzed RTV silicones, amine-catalyzed epoxy resins, and tin-stabilized PVC. In case of doubt, a preliminary test should be carried out.
Thoroughly stir components A and B before each processing step. Measure precisely according to the mixing ratio specified in the TDS (see comparison table above) – ideally by weight. Mix with an electric or pneumatic agitator at low speed (minimize air entrainment). Degas the mixture under vacuum (30–50 mbar) – the material will expand 3–4 times its original volume, bubbles will escape, and the material will settle back after 5–10 minutes. Then slowly pour into the mold from the lowest point to avoid air entrapment. For polyaddition systems, avoid contact with inhibitors (sulfur-based rubber, tin-based RTV, amine epoxides, PVC with tin salts).
Store in the unopened original container in a dry, cool place — typically between +5 and +30 °C, see TDS for exact values. Store components A and B separately; seal airtight after opening. Polyaddition systems are insensitive to moisture, but should be stored in a cool place to maintain pot life. Consult the Safety Data Sheet (SDS) before use.
The comparison table above lists related RTV products with different hardnesses, pot lives, or application profiles. If you are unsure which product is best for you, we would be happy to advise you — contact SILITECH with details of your application (substrate, desired hardness, processing time, mechanical requirements, and durability).
Your question isn't listed here
Our technical team will advise you personally on material selection, processing questions, and individual requirements. Quickly and competently.
Product specifications
| Product information | |
|---|---|
| Container | 500 g or 1 kg or 5 kg |
| brand | Bluesil |
| Manufacturer | Elkem Silicones |
| Mixing ratio | 1 : 1 |
| Networking type | Addition (Platinum) |
| Number of components | 2K (two-component) |
| consistency | Flowable |
| Mixing ratio | 1:1 |
| Other features | |
|---|---|
| UV resistance | Yes |
| Physical properties | |
|---|---|
| Paint has hardened | Transparent |
| Self-leveling | Yes |
| Viscosity uncrosslinked (mPa·s) | 1 |
| Electrical properties | |
|---|---|
| Electrical insulation | Yes |
| Curing values | |
|---|---|
| Potting time (min) | 50 |
| Product approvals | |
|---|---|
| Food contact | No |
| Suitable for medical use | No |
| Keywords | |
|---|---|
| Keywords | |
| processing | |
|---|---|
| Viscosity of mixture | 1,200 mPa·s |
| Viscosity Comp. A | 1,000 mPa·s |
| Viscosity Comp. B | 1,200 mPa·s |
| Pot life at 23°C | 50.0 min |
| Physical & Thermal | |
|---|---|
| Density (23°C) | 0.98 g/cm³ |
| Temperature resistance (duration) | -50 to 200 °C |
| Peak temperature (short-term) | 200 °C |
| Electrical characteristics | |
|---|---|
| Dielectric constant ε (1 kHz) | 2.8 |
| Dielectric strength | 23.0 kV/mm |
| Contact resistance | 1e+15 Ω·cm |
| Loss factor tan δ | 0.001 |
| storage | |
|---|---|
| Shelf life in original packaging | 12 months |
| Storage temperature | -10 to 30 °C |
